Built to the Drawing for Sacramento Architects

Sacramento is the region we know best. Our shop sits in Rocklin, at the top of the capital region and minutes from most job sites in the city, which means an architect drawing a kitchen for an East Sacramento Tudor or a Granite Bay custom home can have the shop at the table rather than at the end of a phone line. This page explains how we support your drawing set: what we need from it, how our shop drawings are organized, which reveal and tolerance conventions we hold, and how the region’s architecture and climate shape the detail. Founded in 2006 and operating as the cabinetry division of Voronenko & Ethen Associates, PineWood is a licensed California contractor (CSLB #1095293) working design and build under one roof.

We begin from your plans, elevations, sections and finish schedule and translate them into detailed, dimensioned shop drawings, with construction, joinery, hardware and finish called out explicitly. Your review and approval of those drawings is the one gate in our workflow: nothing is cut until you have signed off. Before that gate we field-verify the room, because a 1920s service kitchen off the numbered avenues never matches the nominal plan, and we would rather resolve the discrepancy on paper. Where a drawn detail needs a constructability conversation, we raise it on the shop drawings and propose a solution that keeps the drawn proportion rather than one that removes it. The full sequence, from scope review through walk-through, is laid out on our trade process page.

A complete casework specification lets us draw accurately the first time. We ask for construction type (inset face-frame or frameless, with target reveals), species and veneer cut with any grain-matching intent, box and drawer substrates, door and edge profiles, finish system with color and sheen, functional and decorative hardware with finishes, and any code or performance requirement. Our specifications reference walks through each item and explains how we build to it: veneer-core hardwood plywood boxes, solid hardwood face frames, five-piece cope-and-stick or slab doors, and dovetailed solid-wood drawer boxes on concealed full-extension soft-close undermount slides.

Our shop drawings follow the installation conventions of ANSI/AWI 0620-2024, and it helps if your sections do too. Across the construction families the standard covers, the critical reveal is a nominal 3.2 mm, an eighth of an inch, held to a uniform variance of plus or minus .031 inch at Premium grade, .063 at Custom and .094 at Economy. Door and drawer-front edges align within .031, .047 or .063 inch by grade. If the contract documents reference the standard without naming a grade, Custom applies by default, which roughly doubles most visible tolerances relative to Premium, so we encourage you to name the grade in the millwork section.

We draw sections the way we build them: face-frame thickness, reveal at the frame, door and panel thickness, hinge overlay, drawer-front setback and toe-kick height all dimensioned, with finished-end and scribe conditions called out separately. When you send a section with the same information, the first shop-drawing round is a confirmation rather than a translation.

The capital region asks for two quite different kinds of casework. In East Sacramento, the Fabulous Forties and the streets around McKinley Park, the Tudor, Colonial Revival and Mediterranean homes expect a kitchen that reads as part of the original house: inset paint-grade cabinetry, paneled ends, furniture-grade detailing and period moulding profiles matched to the home’s existing woodwork. Those projects often fold a butler’s pantry, breakfast nook and back stair into a single room, and the sections have to reconcile new runs with original trim heights and picture rails. In Land Park and Curtis Park, the Craftsman bungalows and Storybook cottages are short on room, so the drawings reward honest proportion, full-height storage and corner solutions that keep the scale of a bungalow. Midtown and Boulevard Park Victorians bring tall ceilings and trim profiles that deserve to be respected rather than fought. For the Tudor and Colonial Revival stock in particular, our guide to Tudor and Colonial Revival kitchens sets out the profiles and proportions we lean on.

Out in Folsom, El Dorado Hills, Granite Bay and the newer Placer subdivisions, the work shifts to larger custom homes with open great-rooms, where cabinetry defines and anchors the space rather than filling a walled kitchen. Here the drawings tend toward contemporary, wood-forward work: rift white oak and walnut with grain run deliberately across a run of doors, integrated appliance panels, and tall pantry walls that carry the scale of the room. We build to whichever the drawings specify, and because so much Sacramento living spills outdoors for most of the year, we are used to detailing the path from cooktop to patio and the landing zones at a side door.

Sacramento’s hot, dry summers and damper winters move wood through a genuine seasonal swing, and that is a specification question before it is a shop question. Veneer-core hardwood plywood boxes for dimensional stability, solid wood reserved for face frames, doors and mouldings, and floating panels in frame-and-panel doors all respond to it. Finishes are chosen to hold up to valley heat and bright afternoon light; we prepare samples on the actual project species for approval before production and can match a specified sheen. The installation standard treats interior conditioning as a precondition rather than housekeeping, so we confirm with the general contractor that the house is conditioned before delivery.

For Sacramento projects, delivery from our Rocklin shop is a short drive rather than a logistics exercise. That proximity makes the site measure, a finish-sample review at your office or on site, delivery and any punch-list return visit easy to schedule around the general contractor. Our Sacramento builders page covers how we sequence with the GC; if you are working with homeowners directly, our Sacramento homeowner hub describes the same work from their side. Either way, you have one point of contact from scope review to walk-through, and the people who drew the shop drawings are connected to the people building the casework.
